Heat Resistance XLPE Insulation Wire 300V 22AWG Generator XLPE Hook Up Wire

Ask Latest Price
Video Channel
Brand Name :Mysun
Model Number :UL3194
Certification :ROHS/CCC/VDE/CCC/ISO9001:2008
Place of Origin :Guangdong,China
MOQ :3050meters
Price :0.06~0.48USD per M
Payment Terms :T/T, Western Union, MoneyGram
Supply Ability :500000 Meters per Day
Delivery Time :7-15 working day
Packaging Details :Standard packge: cardboard box Accept custom-made.
Conductor Type :Stranded
Color :Brown
Usage :Widely used in home appliance ,lighting ,heater,motor & generator,UAU,robot,industrial power etc
Rated Voltage :600v
Rated Temperature :75C
Size :20AWG
Conductor :Tinned Copper
Standard :UL758
Insulation :XLPE
Type :insulated
Max.Cond Resistance :36.7 Ω/KM
Construction :21/0.18
more
Contact Now

Add to Cart

Find Similar Videos
UL 3271 XLPE Hook Up Wire 600V/125C 18awg Ul758 Red Light Industrial Power Heater 00:46
UL 3271 XLPE Hook Up Wire 600V/125C 18awg Ul758 Red Light Industrial Power Heater
Awm3289 28AWG XLPE Insulated Electrical Cable 11.66mm 00:11
Awm3289 28AWG XLPE Insulated Electrical Cable 11.66mm
22 Gauge UL758 XLPE Insulated Wire Tinned Copper Conductor 00:11
22 Gauge UL758 XLPE Insulated Wire Tinned Copper Conductor
CCC 7.60mm 18AWG XLPE Hook Up Wire For Industrial Machine 00:11
CCC 7.60mm 18AWG XLPE Hook Up Wire For Industrial Machine
Red Headlamp Awm3289 XLPE Insulated Cable 26AWG UL 00:11
Red Headlamp Awm3289 XLPE Insulated Cable 26AWG UL
AWM3321 XLPE Hook Up Wire The company supply  yellow headlamp 00:11
AWM3321 XLPE Hook Up Wire The company supply yellow headlamp
AWM3289 30AWG Factory supply white lights XLPE insulated electrical cable wire 00:22
AWM3289 30AWG Factory supply white lights XLPE insulated electrical cable wire
Fiberglass Braided Electrical Cable silicone insulation wire Heat Proof 00:46
Fiberglass Braided Electrical Cable silicone insulation wire Heat Proof
150C Silicone Rubber Insulated Wire UL3212 305m/ Roll UL Tinned Copper Cable 00:33
150C Silicone Rubber Insulated Wire UL3212 305m/ Roll UL Tinned Copper Cable
View Product Description

XLPE heat resistance insulation wire 300V 22awg xlpe wire and cable

UL 3194 Specifications:

Nominal voltage:600V

Temperature range: 75℃

Standard: UL3194

Insulation: xlpe

Conductor: Tinner copper

Product features:

insulated wire has excellent resistance to high temperature, low temperature resistance, excellent electrical insulation performance,

high voltage resistance, aging resistance, long service life and soft and easy to install.

Product Parameter

Applications:

* Widely used in lighting, household appliances, , lamps.
* electric appliances, instrumentation, motor wiring and electronics.
* gas appliances and other high-temperature environment.

CONDUCTOR INSULATION MAX.COND RESISTANCE UNIT LENGTH(M)(Ft)
SIZE CONSTRUCTION (NO./mm) DIAMETER (mm) NOMINAL THICKNESS (mm) DIAMETER (Ω/KM)
(AWG) (mm)
27 7/0.14 0.42 0.39 1.2 174 305(1000)
26 7/0.16 0.48 1.26 143
24 11/0.16 0.6 1.38 89.3
22 17/0.16 0.76 1.54 56.4
20 21/0.18 0.94 1.72 35.2
18 16/0.254 1.18 1.96 22.2
16 26/0.254 1.5 2.28 14
